Aquaculture / Net cleaning
Aquaculture Net Cleaning Robots
Pengpai Ocean's Net Cleaning ROV uses seawater jets with camera-based monitoring for cage netting. Aqua Robot Supply coordinates configuration and quotation with the manufacturer. Share your net material, cage layout and site conditions before equipment selection.
Request a Quote- Catalogue working depth
- 100 m
- Cleaning-system pressure
- 80 bar
- Catalogue water flow
- 100 L/min
Illustrative context only: not a real farm, supplier project or Pengpai product photograph. No equipment performance or net compatibility is demonstrated.
Manufacturer reference
Cleaning system specifications
Selected Pengpai Ocean Net Cleaning ROV catalogue values. Confirm net compatibility, cleaning settings and shore/deck services for the intended cage before ordering.
On smaller screens, scroll within the table to see all columns.
| Parameter | Catalogue value | System scope | Configuration | Confirm for the site |
|---|---|---|---|---|
| Working depth | 100 m | Cleaning vehicle | Catalogue rating | Cage depth, access and hose/control arrangements. |
| Size / weight | 150 × 80 × 60 cm; 105 kg | Vehicle / air net weight | Catalogue reference | Handling, lifting, access and deployment method. |
| Jet system | 80 bar; 100 L/min | Cleaning pressure and flow | 1.2–2.0 mm nozzles listed | Nozzle choice, settings and net-material compatibility; no universal wear or cleaning-rate guarantee. |
| Input supply | 230 VAC; 10 kW | Power requirement | 3-phase, 50–60 Hz listed | Confirm the stated electrical package with the manufacturer against your local supply. |
| Visual monitoring | 4 cameras; 4 lights | Ethernet IP cameras / LED lamps | 4 recording channels listed | Visibility, recording requirements and the control-console scope. |
| Control / motion | 6 thrusters; 0–1.5 m/s | Vehicle control | Automatic depth and net-washing functions listed | Cage layout, fouling and cleaning path; supervision and operating procedure. |
Source: uploaded Pengpai Ocean catalogue. The category-style product name has no confirmed separate model number. Ratings are manufacturer statements, not measured output at your farm.
- The brochure's cleaning-efficiency and cage-wear statements are not site guarantees. The opening image is an AI-generated net-environment illustration, not a photograph of the cleaning system. A model-matched equipment image is still required.
Configuration
Cage and deployment requirements
Net geometry and operating conditions need to be assessed with the manufacturer. A pressure rating alone does not establish cleaning suitability for a particular farm.
Catalogue system
The documented system combines a six-thruster vehicle, seawater-jet cleaning, camera/light monitoring and a mobile control console. Confirm the supplied power cabinet, hose, shore/deck services and handling equipment.
Confirm in the quotation
- Net material, coating, mesh size, fouling and manufacturer-approved cleaning settings.
- Cage walls/bottom, obstructions, access and cleaning-path arrangements.
- Power compatibility, hose/control routing and deployment/recovery scope.
No guaranteed cleaning rate, wear reduction or compatibility with every net is claimed. Manufacturer documentation and site-specific configuration should be reviewed before purchase.
Information to share
- Cage dimensions and depth, net specifications and site drawings if available.
- Typical fouling, water conditions and intended operating procedure.
- Available power, vessel/shore access, lifting and hose arrangements.
Project quotation
Discuss your equipment requirements
Discuss your task, site conditions and preferred equipment for a project-specific quotation.
Website form submission is not enabled. Use email or WhatsApp.
